A compact nano-flow UHPLC system

The EASY-nLC combines simplicity and high-throughput capacity in a nano-flow UHPLC with a pressure rating of 1200 bar.

System specifications

Specification Value
Pressure range 0 – 1200 bar
Flow range, gradient 20 – 2000 nL/min (recommended 100 – 1000 nL/min)
Flow range, loading & equilibration up to 25 µL/min
Retention time reproducibility 0.1 – 0.4% RSD within recommended flow range
Pick-up volume range 0.10 – 18.00 µL (20 µL loop)
Injection reproducibility ≤ 0.2% RSD at 5 µL pick-up; ≤ 3.0% RSD at 0.1 µL pick-up
Injection linearity R ≥ 0.9985 for 0.5 – 10 µL; R ≥ 0.9995 for 0.3 – 1.6 µL
Carry-over < 0.05% (caffeine)
Gradient delay volume < 1 µL (mixing tee to venting tee)
